Micro H-1™ 2 MOA - Red dot reflex sight with standard mount for Weaver/Picatinny - 1
Micro H-1™ 2 MOA - Red dot reflex sight with standard mount for Weaver/Picatinny - 2
Micro H-1™ 2 MOA - Red dot reflex sight with standard mount for Weaver/Picatinny - 3
Micro H-1™ 2 MOA - Red dot reflex sight with standard mount for Weaver/Picatinny - 4

Intended use

  • Hunting

    Hunting

  • Shooting Sports

    Shooting Sports

  • Personal Protection

    Personal Protection

  • Secondary Optic

    Secondary Optic

Micro H-1™2 MOA - Red dot reflex sightwith standard mount for Weaver/Picatinny

#200018

  • 50,000 hours (over 5 years) of operation on one battery

  • Submersible to 5 meters (15 feet)

  • Lightweight – 84 g (3.0 oz) sight only and 116 g (4.1 oz) with mount

  • Height of Optical Axis 19 mm (0.7 in) measured from top surface of mechanical interface

  • 12 intensity settings for use in daylight and low light conditions

  • 2 MOA dot size

Product description

The Aimpoint® Micro H-1 was designed with the hunter in mind. It has become a very popular hunting sight worldwide due to its size, light weight and robust build quality.

This small sight model is available in two MOA sizes; 2 and 4 MOA. It is rugged and reliable, for increased confidence in the harshest of elements.

The Aimpoint Micro H-1 is among the lightest red dot sights on the market and still tough enough to carry the Aimpoint name.

Inspiration

Please note that displayed media files highlight selected sight model and not always the mount configuration and accessories included in selected item number.

Specifications & documents

  • General specifications
  • Optical Information
  • Power Source Information
  • Mounting specifications
  • Physical Information
  • Technology Information
  • Environmental Information
  • Documents and zeroing targets

General specifications

Size L x W x H
Size L x W x H
69 x 42 x 41 mm / 2.7 x 1.7 x 1.6 in
Weight
Weight
116 g / 4.1 oz
Dot size
Dot size
2 MOA
Magnification
Magnification
1X - No Magnification
NVD compatible
NVD compatible
No
Transmission
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Eye relief
Unlimited
Mounting solution
Mounting solution
Micro Standard Mount for Weaver / Picatinny
Mounting platform
Mounting platform
Weaver / Picatinny Rail

Optical Information

Dot size
2 MOA
* MOA (minute of angle)
1 MOA ≈ 30 mm at 100 meters ≈ 1 in at 100 yards
Magnification
1X - No Magnification
NVD compatible
No
Transmission
Average 60% in the range 420 - 700 nm
Eye relief
Unlimited
Dot color
Red
Light source wavelength
650 nm red light
Optical coating
Anti-reflex coating all surfaces and multilayer coating objective lens
Parallax
Operationally parallax free - No centering required
Diode
LED (Light Emitting Diode) totally eye safe

Power Source Information

Battery life
50,000 h at daylight setting 8 (15,000 Lux, room temperature)
Battery type
CR2032, 3V, Lithium
Power switch
Rotary Switch
Daylight settings (DL)
12

Mounting specifications

Torque - Mount to sight
0.8 Nm / 7 in-lbs (Torx T10)
Torque - Mount to rail
2.0 Nm / 18 in-lbs (Torx T10)
Mounting solution
Micro™ Standard Mount for Weaver / Picatinny

Physical Information

Material housing and tube
High Strength Aluminum
Surface finish housing
Anodized, Semi-matte
Color housing
Black
Lens covers
Bikini Lens Cover, Rubber, Solid
Adjustment 1 click =
1 click = 13 mm at 100 m / 0.5 in at 100 yds
Size L x W x H - Sight only
61 x 41 x 36 mm / 2.4 x 1.6 x 1.4 in
Size L x W x H
69 x 42 x 41 mm / 2.7 x 1.7 x 1.6 in
Weight - Optic only
84 g / 3 oz
Weight
116 g / 4.1 oz

Technology Information

Operating principle
Reflex collimator sight - red dot sight

Environmental Information

Water resistant
5 m / 15 ft
Operating temperature
- 30°C to + 60°C / - 20°F to + 140°F
Storage temperature
- 51°C to + 71°C / - 60°F to + 160°F
Temperature shock
Operable after a temperature shock between - 30°C and + 60°C (- 22°F and + 140°F)
Humidity
Operable during and after Humidity. Limits: RH: 95%, Temp: +20°C to +50°C (+68°F to +122°F), cyclic
Vibration
Withstands Vibration. Limits: Vibration, sinusoidal in a frequency range of 10-150 Hz. Frequency: 10-30 Hz, ±1.587 mm, Frequency: 30-150 Hz. 5.75 g, 1 octave/min. Direction: X, Y and Z, Time: 30 min/direction.
Shock
Operable before and after shock. Limits: X-axis: 500 g, 0.7 – 1.1 ms (3 shocks), Y-axis: 40g ±4g, 11 ±1ms (2 shocks in each direction, Z-axis: 40g ±4g, 11 ±1ms, 2 shocks in each direction.
